April 2022

Model of the Month

Did you know you can model a power-on reset (POR) circuit with just three XMODEL primitives?

Check out this step-by-step guide on how to run a set of repeated simulations with randomized parameter values.

Now with the newly added 'period' parameter, the 'exp_gen' primitive can produce periodically-repeating exponential waveforms.

Starting with 2022.02 release, GLISTER can generate XMODEL netlists from testbench schematics containing 'analogLib' cells.

Silicon Photonics Simulation with XMODEL, Measuring I-V Curves, and More

Catching Elusive Voltage Spikes with Assertions, Modeling VCO with Extra Digital Inputs, and More

Modeling Delta-Sigma Digital-to-Analog Converters, XMODEL at DVCon US, and More

Modeling Mixed-Signal Processing-in-Memory Circuits, Filtering Phase Noise, and More

Modeling a Digital LDO, Tips on Modeling High-Pass Filters, and More
