XMODEL : Empower SystemVerilog
with Event-Driven Analog Models

XMODEL
Empower SystemVerilog with Event-Driven Analog Models

Analog/Mixed-Signal Models

XMODEL
Primitives
Library

XMODEL Primitives Library

SystemVerilog
Simulator

SystemVerilog Simulator

XMODEL
Simulation
Engine

XMODEL Simulation Engine

Simulation Results

XMODEL is an extension to your existing SystemVerilog simulator such as VCS, NC-Verilog/Xcelium, and Questa/ModelSim, enabling fast and accurate simulation of analog/mixed-signal systems with functional models and circuit-level models.

Since XMODEL can perform analog simulation entirely in SystemVerilog without involving SPICE, it is ideally suited for verifying large, complex mixed-signal systems where the mixture of digital and analog poses challenges to the existing tools such as SPICE, Verilog-AMS, and Real-Number Verilog.

Introduction
What is XMODEL?

Demo 1
XMODEL vs Real-Number Verilog

Demo 2
Learning XMODEL Primitives with Phase-Locked Loop(PLL) Modeling

Feature 1

Event-Driven Simulation with XMODEL Functional Models

XMODEL uses revolutionary, patented algorithms to express analog waveforms in functional expressions and compute them efficiently in an event-driven fashion.

As a result, the functional models composed with XMODEL primitives in SystemVerilog can achieve up to 10~100x speed-up over Verilog-AMS or Real-Number Verilog, which must compute all the values on the waveform for accurate results.

XMODEL vs Other Simulators

Feature 2

Quick and Easy Model Building with XMODEL Primitives

XMODEL provides a rich set of primitives that you can build analog models and testbenches with. Just connect them up as building blocks; unlike Real-Number Verilog, virtually no programming is required. XMODEL primitives are extensive and parameterized; use them as basic operators to build your own component library!

XMODEL Primitives

Feature 3

Circuit-Level Simulation in SystemVerilog with XMODEL

In addition to the functional primitives, XMODEL also provides a set of circuit-level primitives such as resistors, capacitors, transistors, and even transmission lines. With these circuit-level primitives, one can easily compose models with various analog effects such as loading, nonlinearity, switching, and multiple drivers, which is not directly supported by Real-Number Verilog (a.k.a. wreal models). Yet, the simulation still runs entirely in SystemVerilog without invoking SPICE.

Circuit-Level Modeling

Feature 4

Efficient Time-Domain Noise Simulation

XMODEL has a unique capability of computing the signal's statistical property during time-domain simulation, with significant speed-ups over the traditional Monte-Carlo simulations. For instance, it takes only about 10 seconds to estimate the bit-error rate (BER) of a high-speed wireline transceiver down to 10-12.

Eye Diagram

BER Bathtub

Feature 5

XMODEL-SPICE Co-simulation

When supported by your SystemVerilog simulator, XMODEL modules can interface with SPICE netlists as well as Verilog-AMS or Real-Number Verilog modules. With this co-simulation feature, you can verify your model's equivalence with the circuit by comparing their respective responses to the same testbench and stimuli written in XMODEL.

Feature 6

Batch simulation processing with XMULAN

XMULAN is an extensive Python library included in the XMODEL package that allows you to streamline XMODEL simulations and post-process their results. With XMULAN, you can write Python scripts that perform simulations while sweeping parameters, collect results, and post-process them for display or recording.
