PRIMITIVE OF THE MONTH
inv_func
This primitive computes a reciprocal of an xreal-typed input.
May 2020
TIP OF THE MONTH
Modeling a digital gate with unequal rising and falling delays
Here is a simple trick to model a digital buffer with unequal rising and falling delays using 'transition' and 'slice' primitives.
XMODEL RELEASE UPDATES
2020.05 Release
This release adds many new features and primitives, including the flicker noise modeling in the clock-generating primitives and improved channel fitting with the sparam_to_tf script.
UPCOMING EVENT
DAC 2020 going virtual on July 20-24
Don't miss this opportunity to check out the latest updates on XMODEL while staying healthy!
