New Tutorial
Modeling and Simulation of Analog-to-Digital Converters with XMODEL
Check out this latest tutorial on modeling and simulation of a pipelined ADC example both in top-down and bottom-up fashions.
September 2021
Primitive of the Month
adc
This primitive models an ideal analog-to-digital converter with arbitrary resolution.
Tip of the Month
Removing glitches in bus signals
Learn how to remove glitches in the ADC outputs due to the timing difference of the individual bits.
XMODEL Release Updates
2021.09 Release
This release adds a new tutorial on ADC modeling, 'inductor.py' UDM for multi-port inductors/transformers, and MODELZEN support for Spectre's 'nport' elements.
