Upcoming Event
Meet Scientific Analog at DVCon Europe 2024
Join us in Munich to explore XMODEL! Seoul National University will present a UVM testbench that verifies the global convergence property of an adaptive decision feedback equalizer.
September 2024
Model of the Month
Modeling an SRAM array
This application note demonstrates how to model a simple 8x64 SRAM array using XMODEL primitives.
Tip of the Month
Suppressing X and Z values in digital signals
The parameters 'valueX' and 'valueZ' have been newly introduced to certain XMODEL primitives to map X (unknown) and Z (high-impedance) values to 0 or 1.
Primitive of the Month
integ_mod
This primitive performs circular integration on an xreal-type input, computing the remainder of the signal's time integral divided by a specified modulus. It is useful when generating periodic signals with variable frequencies.
Latest Issues
September 2024
XMODEL at DVCon Europe 2024, Modeling SRAM Array, and More
August 2024
Modeling PCIe Receiver Detection Circuit, Exporting XWAVE Analysis Results, and More
July 2024
Webinar on Silicon Photonics Modeling & Simulation, Modeling Nonlinear PAM4 Transmitters, and More
June 2024
XMODEL at DAC 2024, Modeling an Adaptive DFE Receiver, and More
May 2024
Modeling a Phase Interpolator with INL/DNL, Using PSL Assertions for Analog Checks, and More
